Detailed Description

Meshing defined in the Euclidean space

Public Member Functions
	MeshSphericalExt ()

	MeshSphericalExt (const MeshSphericalExt &m)

MeshSphericalExt &	operator= (const MeshSphericalExt &m)

virtual	~MeshSphericalExt ()

Id	resetFromDb (Db dbin, Db dbout, const String &triswitch="nqQ", bool verbose=false)

Public Member Functions inherited from gstlrn::MeshSpherical
	MeshSpherical (const MatrixDense &apices=MatrixDense(), const MatrixInt &meshes=MatrixInt())

	MeshSpherical (const MeshSpherical &m)

MeshSpherical &	operator= (const MeshSpherical &m)

virtual	~MeshSpherical ()

String	toString (const AStringFormat *strfmt=nullptr) const override
	Interface to AStringable.

Id	getNApices () const override
	Interface to AMesh.

Id	getNMeshes () const override

double	getMeshSize (Id imesh) const override

Id	getApex (Id imesh, Id rank) const override

double	getCoor (Id imesh, Id rank, Id idim) const override

double	getApexCoor (Id i, Id idim) const override

Id	getEmbeddedNDim () const override

void	getEmbeddedCoorPerMesh (Id imesh, Id ic, 1 &coords) const override

void	getEmbeddedCoorPerApex (Id iapex, 1 &coords) const override

void	getBarycenterInPlace (Id imesh, vect coord) const override

Id	reset (Id ndim, Id napexpermesh, const 1 &apices, const 1 &meshes, bool byCol, bool verbose=false)

Id	getVariety () const override

const MatrixDense &	getApices () const

const MatrixInt &	getMeshes () const

	getMeshesAsVVI () const

Public Member Functions inherited from gstlrn::AMesh
	AMesh ()

	AMesh (const AMesh &m)

AMesh &	operator= (const AMesh &m)

virtual	~AMesh ()

virtual Id	getNApexPerMesh () const
	Interface for AMesh.

virtual void	getCoordinatesPerMeshInPlace (Id imesh, Id rank, 1 &coords) const

virtual void	getApexCoordinatesInPlace (Id i, 1 &coords) const

virtual void	resetProjFromDb (ProjMatrix m, const Db db, Id rankZ=-1, bool verbose=false) const

ProjMatrix *	createProjMatrix (const Db *db, Id rankZ=-1, bool verbose=false) const

Id	getNDim () const

double	getExtendMin (Id idim) const

double	getExtendMax (Id idim) const

	getExtrema (Id idim) const

void	getElements (MatrixDense &apices, MatrixInt &meshes) const

Id	isCompatibleDb (const Db *db) const

	getMeshSizes () const

void	printMesh (Id imesh0=-1) const

void	printMeshes (Id level=0, Id nline_max=-1) const

	getCoordinatesPerApex (Id idim) const

	getMeshByApexPair (Id apex1, Id apex2) const

	getCoordinatesPerMesh (Id imesh, Id idim, bool flagClose=false) const

	getApexCoordinates (Id iapex) const

	getCoordinatesPerMesh (Id imesh) const

	getEmbeddedCoordinatesPerMesh (Id imesh=0) const

void	getEmbeddedCoordinatesPerMeshInPlace (Id imesh, 1 &vec) const

	getEmbeddedCoordinatesPerApex () const

	getDistances (Id iapex0, const 1 &japices=1()) const

	getAllCoordinates () const

MatrixDense	getAllApices () const

MatrixInt	getAllMeshes () const

double	getCenterCoordinate (Id imesh, Id idim) const

	getAllCenterCoordinates () const

	getNeighborhoodPerMesh () const

	getNeighborhoodPerApex () const

Public Member Functions inherited from gstlrn::AStringable
	AStringable ()

	AStringable (const AStringable &r)

AStringable &	operator= (const AStringable &r)

virtual	~AStringable ()

virtual void	display (const AStringFormat *strfmt=nullptr) const final

virtual void	display (Id level) const final

Public Member Functions inherited from gstlrn::ASerializable
	ASerializable ()

	ASerializable (const ASerializable &r)

ASerializable &	operator= (const ASerializable &r)

	ASerializable (ASerializable &&r) noexcept

ASerializable &	operator= (ASerializable &&r) noexcept

virtual	~ASerializable ()

bool	dumpToNF (const String &NFFilename, const EFormatNF &format=EFormatNF::fromKey("DEFAULT"), bool verbose=false) const
	Dump the contents of an object into an Output File using a given Output NF Format.

void	setDefaultFormatNF (const EFormatNF &format)

Static Public Member Functions
static AMesh *	spde_mesh_load (Db dbin, Db dbout=nullptr, const 1 &gext=1(), const String &triswitch="-r2", bool verbose=false)

Static Public Member Functions inherited from gstlrn::MeshSpherical
static MeshSpherical *	createFromNF (const String &NFFilename, bool verbose=true)

static MeshSpherical *	create (const MatrixDense &apices=MatrixDense(), const MatrixInt &meshes=MatrixInt())

Static Public Member Functions inherited from gstlrn::AMesh
static void	dumpNeighborhood (std::vector< 1 > &Vmesh, Id nline_max=1)

Static Public Member Functions inherited from gstlrn::ASerializable
static String	buildFileName (Id status, const String &filename, bool ensureDirExist=false)

static String	getFileIdentity (const String &filename, bool verbose=false)

static void	setPrefixName (const String &prefixName)

static void	unsetPrefixName ()

static const String &	getPrefixName ()

Constructor & Destructor Documentation

◆ MeshSphericalExt() [1/2]

gstlrn::MeshSphericalExt::MeshSphericalExt ( )

◆ MeshSphericalExt() [2/2]

gstlrn::MeshSphericalExt::MeshSphericalExt ( const MeshSphericalExt & m )

◆ ~MeshSphericalExt()

gstlrn::MeshSphericalExt::~MeshSphericalExt ( )

virtual

Member Function Documentation

◆ operator=()

MeshSphericalExt & gstlrn::MeshSphericalExt::operator= ( const MeshSphericalExt & m )

◆ resetFromDb()

Id gstlrn::MeshSphericalExt::resetFromDb	(	Db *	dbin,
		Db *	dbout,
		const String &	triswitch = `"nqQ"`,
		bool	verbose = `false`
	)

Create the meshing

Parameters

[in]	dbin	Pointer to the input Db (optional)
[in]	dbout	Pointer to the output Db (optional)
[in]	triswitch	Construction switch
[in]	verbose	Verbose flag

◆ spde_mesh_load()

AMesh * gstlrn::MeshSphericalExt::spde_mesh_load	(	Db *	dbin,
		Db *	dbout = `nullptr`,
		const 1 &	gext = `1()`,
		const String &	triswitch = `"-r2"`,
		bool	verbose = `false`
	)

static

Load the AMesh structure

Returns: Pointer on the newly allocated AMesh
