Detailed Description

Class for performing Boolean simulation.

A Boolean simulation results in drawing random object into a Field conditionally to existing samples or not These objects are called tokens and are generated according to:

their type (extension, orientation, ...)
their proportion: fix or variable

The samples (used for conditional simulations) are defined in input Db (as Z Locator variable) and are set to 0 (pore) or 1 (grain) If the proportion is variable, it uses Proportion locator in output DbGrid

Public Member Functions
	SimuBoolean (Id nbsimu=0, Id seed=4324324)

	SimuBoolean (const SimuBoolean &r)=delete

SimuBoolean &	operator= (const SimuBoolean &r)=delete

virtual	~SimuBoolean ()

String	toString (const AStringFormat *strfmt=nullptr) const override
	Interface to AStringable.

Id	simulate (Db dbin, DbGrid dbout, ModelBoolean *tokens, const SimuBooleanParam &boolparam, Id iptr_simu, Id iptr_rank, Id iptr_cover, bool verbose=false)

	extractObjects () const

Public Member Functions inherited from gstlrn::ACalcSimulation
	ACalcSimulation (Id nbsimu, Id seed=4324324)

	ACalcSimulation (const ACalcSimulation &r)=delete

ACalcSimulation &	operator= (const ACalcSimulation &r)=delete

virtual	~ACalcSimulation ()

Id	getSeed () const

Id	getNbSimu () const

void	setSeed (Id seed)

void	setNbSimu (Id nbsimu)

Public Member Functions inherited from gstlrn::ACalcInterpolator
	ACalcInterpolator ()

	ACalcInterpolator (const ACalcInterpolator &r)=delete

ACalcInterpolator &	operator= (const ACalcInterpolator &r)=delete

virtual	~ACalcInterpolator ()

void	setModel (ModelGeneric *model)

void	setNeigh (ANeigh *neigh)

void	setKrigopt (const KrigOpt &krigopt)

ModelGeneric *	getModel () const

ANeigh *	getNeigh () const

const KrigOpt &	getKrigopt () const

bool	hasModel (bool verbose=true) const

bool	hasNeigh (bool verbose=true) const

Public Member Functions inherited from gstlrn::ACalcDbToDb
	ACalcDbToDb (bool mustShareSameSpaceDimension=true)

	ACalcDbToDb (const ACalcDbToDb &r)=delete

ACalcDbToDb &	operator= (const ACalcDbToDb &r)=delete

virtual	~ACalcDbToDb ()

void	setDbin (Db *dbin)

void	setDbout (Db *dbout)

void	setNamingConvention (const NamingConvention &namconv)

void	setMustShareSpaceDimension (bool mustShareSpaceDimension)

Db *	getDbin () const

Db *	getDbout () const

DbGrid *	getGridin () const

DbGrid *	getGridout () const

const NamingConvention &	getNamingConvention () const

bool	hasDbin (bool verbose=true) const

bool	hasDbout (bool verbose=true) const

bool	isGridIn (bool verbose=true) const

bool	isGridOut (bool verbose=true) const

Public Member Functions inherited from gstlrn::ACalculator
	ACalculator ()

	ACalculator (const ACalculator &r)=delete

ACalculator &	operator= (const ACalculator &r)=delete

virtual	~ACalculator ()

bool	run ()

Public Member Functions inherited from gstlrn::AStringable
	AStringable ()

	AStringable (const AStringable &r)

AStringable &	operator= (const AStringable &r)

virtual	~AStringable ()

virtual void	display (const AStringFormat *strfmt=nullptr) const final

virtual void	display (Id level) const final

Constructor & Destructor Documentation

◆ SimuBoolean() [1/2]

gstlrn::SimuBoolean::SimuBoolean	(	Id	nbsimu = `0`,
		Id	seed = `4324324`
	)

◆ SimuBoolean() [2/2]

gstlrn::SimuBoolean::SimuBoolean ( const SimuBoolean & r )

delete

◆ ~SimuBoolean()

gstlrn::SimuBoolean::~SimuBoolean ( )

virtual

Member Function Documentation

◆ extractObjects()

gstlrn::SimuBoolean::extractObjects ( ) const

◆ operator=()

SimuBoolean & gstlrn::SimuBoolean::operator= ( const SimuBoolean & r )

delete

◆ simulate()

Id gstlrn::SimuBoolean::simulate	(	Db *	dbin,
		DbGrid *	dbout,
		ModelBoolean *	tokens,
		const SimuBooleanParam &	boolparam,
		Id	iptr_simu,
		Id	iptr_rank,
		Id	iptr_cover,
		bool	verbose = `false`
	)

◆ toString()

String gstlrn::SimuBoolean::toString ( const AStringFormat * strfmt = nullptr ) const

overridevirtual

Interface to AStringable.

Reimplemented from gstlrn::AStringable.

The documentation for this class was generated from the following files:

include/Simulation/SimuBoolean.hpp
src/Simulation/SimuBoolean.cpp
